PRODUCT DETAILS

Din Rail Power Supply – CCTV- Option 3

Rated 5.00 out of 5 based on 3 customer ratings

This Din Rail Power Supply for CCTV is of high efficiency, long life, and great stability. It also provides multi-protection against over-loading, over-current, short-circuit, and over-heating.

Category DIN Rail Type CCTV Power Supply

Din Rail Power Supply – CCTV – Option 3

A 12VDC / 5Amp to 7Amp SMPS
This Din rail power supply for CCTV is also available in a Metal cabinet
Preset to adjust voltage available.
Comes in a wide input range of 100VAC – 300VAC.
Has an input connect of 3 pin cord on LNE available.
Also has an output of 2 terminals available.
An SMPS that converts an unstabilized input voltage into a regulated output voltage.
Are also characterized by their significantly higher efficiency and lower weight.
Comes in a more compact design than linearly regulated power supplies (transformers).
Comes in a CCCV circuit with din rail mounting.
Also has multiple LED indications for easy usage.

Mounting Type

Model No.	MRE28b
Output Voltage	12VDC / 5Amp to 7Amp
Input Voltage	100VAC – 275VAC
Input Connector	3 Pin Cord on LNE.
Output Connector	Output 2 way Terminal
LED Indication	Green LED indicates power ON RED LED indicates OVER LOAD Please reduce the load if RED LED glows.
Mounting	Din Rail
Feature	CCCV Circuit
Dimension	134mm(L) X 101mm(W) X 60mm(H).
